| Machinery Size | ||
|---|---|---|
| (mm) | Total Length | 2840 |
| (mm) | Total Width | 880 |
| (kg) | Machine Weight (with all fluids) | 870 |
| (mm) | Canopy Height | 2220 |
| (mm) | Axle Base | 900 |
| (mm) | Wheel (track) Distance | 660 |
| (mm) | Minimum Ground Clearance | 132 |
| (mm) | Tail Swing Radius | 800 |
| Tech. Specifications | ||
| (㎡/mm) | Standard Bucket Capacity/Length | 0.023/380 |
| (rmp) | Swing Speed | 0-13 |
| (°) | Gradeability | 30 |
| (KN) | Max. Bucket Digging Force | 7.2 |
| (KN) | Max. Arm Digging Force | 4.6 |
| Engine Model | KUBOTA Z482 | |
| (Kw(HP)/rpm) | Power/Revolution speed | 7(9.3)/3000 |
| (MPa) | System Pressure | 16 |
| (L) | Fuel Tank Capacity | 4 |
| (L) | Hydraulic Circuit Capacity | 10 |
| (L) | Cooling Circuit Capacity | 3 |
| (L) | Engine Oil Capacity | 1.8 |
| (m³) | Bucket capacity | 0.023 |
| Working Range | ||
| (mm) | Max. Digging Height | 2600 |
| (mm) | Max. Dumping Height | 1380 |
| (mm) | Max. Digging Depth | 1715 |
| (mm) | Max. Vertical Digging Depth | 1590 |
| (mm) | Max. Digging Radius | 3065 |
| (mm) | Max. Swing Radius | 1480 |
| Machinery Size | ||
|---|---|---|
| Total Length | ||
| (mm) | 2840 | |
| Total Width | ||
| (mm) | 880 | |
| Machine Weight (with all fluids) | ||
| (kg) | 870 | |
| Canopy Height | ||
| (mm) | 2220 | |
| Axle Base | ||
| (mm) | 900 | |
| Wheel (track) Distance | ||
| (mm) | 660 | |
| Minimum Ground Clearance | ||
| (mm) | 132 | |
| Tail Swing Radius | ||
| (mm) | 800 | |
| Tech. Specifications | ||
| Standard Bucket Capacity/Length | ||
| (㎡/mm) | 0.023/380 | |
| Swing Speed | ||
| (rmp) | 0-13 | |
| Gradeability | ||
| (°) | 30 | |
| Max. Bucket Digging Force | ||
| (KN) | 7.2 | |
| Max. Arm Digging Force | ||
| (KN) | 4.6 | |
| Engine Model | ||
| KUBOTA Z482 | ||
| Power/Revolution speed | ||
| (Kw(HP)/rpm) | 7(9.3)/3000 | |
| System Pressure | ||
| (MPa) | 16 | |
| Fuel Tank Capacity | ||
| (L) | 4 | |
| Hydraulic Circuit Capacity | ||
| (L) | 10 | |
| Cooling Circuit Capacity | ||
| (L) | 3 | |
| Engine Oil Capacity | ||
| (L) | 1.8 | |
| Bucket capacity | ||
| (m³) | 0.023 | |
| Working Range | ||
| Max. Digging Height | ||
| (mm) | 2600 | |
| Max. Dumping Height | ||
| (mm) | 1380 | |
| Max. Digging Depth | ||
| (mm) | 1715 | |
| Max. Vertical Digging Depth | ||
| (mm) | 1590 | |
| Max. Digging Radius | ||
| (mm) | 3065 | |
| Max. Swing Radius | ||
| (mm) | 1480 | |
