| Machinery Size | ||
|---|---|---|
| (mm) | Total Length | 3335 |
| (mm) | Total Width | 990/1300 |
| (mm) | Track Width | 200 |
| (kg) | Machine Weight (with all fluids) | 1530 |
| (mm) | Canopy Height | 2270 |
| (mm) | Axle Base | 1215 |
| (mm) | Wheel (track) Distance | 790 |
| (mm) | Minimum Ground Clearance | 153 |
| (mm) | Tail Swing Radius | 655 |
| Tech. Specifications | ||
| (㎡/mm) | Standard Bucket Capacity/Length | 0.025/380 |
| (rmp) | Swing Speed | 1-13 |
| (°) | Gradeability | 30 |
| (KN) | Max. Bucket Digging Force | 9 |
| (KN) | Max. Arm Digging Force | 5.5 |
| Engine Model | KUBOTA D722 | |
| (Kw(HP)/rpm) | Power/Revolution speed | 10.2[13.8]/2500 |
| (MPa) | System Pressure | 17 |
| (L) | Fuel Tank Capacity | 14.5 |
| (L) | Hydraulic Circuit Capacity | 21 |
| (L) | Cooling Circuit Capacity | 5 |
| (L) | Engine Oil Capacity | 2.5 |
| (m³) | Bucket capacity | 0.025 |
| Working Range | ||
| (mm) | Max. Digging Height | 2961 |
| (mm) | Max. Dumping Height | 2083 |
| (mm) | Max. Digging Depth | 1953 |
| (mm) | Max. Vertical Digging Depth | 1859 |
| (mm) | Max. Digging Radius | 3519 |
| (mm) | Max. Swing Radius | - |
| (mm) | MAx. Dozer Blade Lifting Distance | 224 |
| (mm) | MAx. Dozer Blade Cutting Distance | 237 |
| Machinery Size | ||
|---|---|---|
| Total Length | ||
| (mm) | 3335 | |
| Total Width | ||
| (mm) | 990/1300 | |
| Track Width | ||
| (mm) | 200 | |
| Machine Weight (with all fluids) | ||
| (kg) | 1530 | |
| Canopy Height | ||
| (mm) | 2270 | |
| Axle Base | ||
| (mm) | 1215 | |
| Wheel (track) Distance | ||
| (mm) | 790 | |
| Minimum Ground Clearance | ||
| (mm) | 153 | |
| Tail Swing Radius | ||
| (mm) | 655 | |
| Tech. Specifications | ||
| Standard Bucket Capacity/Length | ||
| (㎡/mm) | 0.025/380 | |
| Swing Speed | ||
| (rmp) | 1-13 | |
| Gradeability | ||
| (°) | 30 | |
| Max. Bucket Digging Force | ||
| (KN) | 9 | |
| Max. Arm Digging Force | ||
| (KN) | 5.5 | |
| Engine Model | ||
| KUBOTA D722 | ||
| Power/Revolution speed | ||
| (Kw(HP)/rpm) | 10.2[13.8]/2500 | |
| System Pressure | ||
| (MPa) | 17 | |
| Fuel Tank Capacity | ||
| (L) | 14.5 | |
| Hydraulic Circuit Capacity | ||
| (L) | 21 | |
| Cooling Circuit Capacity | ||
| (L) | 5 | |
| Engine Oil Capacity | ||
| (L) | 2.5 | |
| Bucket capacity | ||
| (m³) | 0.025 | |
| Working Range | ||
| Max. Digging Height | ||
| (mm) | 2961 | |
| Max. Dumping Height | ||
| (mm) | 2083 | |
| Max. Digging Depth | ||
| (mm) | 1953 | |
| Max. Vertical Digging Depth | ||
| (mm) | 1859 | |
| Max. Digging Radius | ||
| (mm) | 3519 | |
| Max. Swing Radius | ||
| (mm) | - | |
| MAx. Dozer Blade Lifting Distance | ||
| (mm) | 224 | |
| MAx. Dozer Blade Cutting Distance | ||
| (mm) | 237 | |
