SKID LOADER ZS14A

Serial Number : 1RG8721

AVAILABLE NOW : Kraluv Dvur (CZ)

1070mm Bucket Integrated Manual Quick Coupler Hydraulic Controls Hydraulic Transmission 3-Way Auxiliary Hydraulics

Select Additional Options:

Extended Warranty

Extended Warranty
Close

It is possible to extend the 2 years warranty, adding additional years. Check the FAQ for more information about the warranty extension.

3 years or 3000 hours(+$1,220.00)
Select Click to Deselect

4 years or 4000 hours(+$2,092.00)
Select Click to Deselect

The Skid loader ZAOX ZS14A is a compact machine with an operating weight of about 1375 Kg, powered by a Euro V Kubota D1105 engine with low fuel consumption.

The machine is equipped with a bucket with a capacity of 0.2 m3, 1070 mm wide and reached the real dumping height of 2000 mm.

Compactness and ease of use, together with various attachments, make this vehicle an ideal companion for any type of company.

Your configuration

SKID LOADER ZS14A
Serial Number :1RG8721 ($17,529.60)

Factory Options:

Total Price

$17,529.60

Submit Reservation

Discount : 12.00 % OFF
(Sticker Price : $19,920.00 )

Discount is not applied on Factory Options and Accessories.
All prices are without VAT

Submit the order is without obligation and it is not binding!

One of our sales manager will contact you by message or telephone to discuss your possible purchase in the next 48 hours.

Machinery Size
(mm)	Overall Operating Height	3400
(mm)	Height to top of cab	1813
(mm)	Length Without Bucket	2200
(mm)	Overall Length with Bucket	2950
(mm)	Width	920
(mm)	Bucket Width	1070
(mm)	Height to bottom of flat bucket	2446
(mm)	Height to Bucket Hinge Pin	2500
(mm)	Wheelbase	801
(mm)	Ground Clearance	145
(°)	Angle of Departure	20
(mm)	Distance Between the Rear Axle and the Bumper	910
(mm)	Tread Width	785
Tech. Specifications
(m³)	Bucket capacity	0.2
(km/h）	Max Speed	9
(L/min)	Rated flux	50
(L/min)	High Flow Flux	/
(Kg)	Operative weight	1375
	Engine Model	Kubota D1105
(Kw(HP)/rpm)	Power/revolution speed	18,2[24.7]/3000
(L)	Fuel tank capacity	28
(kg)	Operating load	380
Working Range
(mm)	Dumping height	2000
(°)	Dumping angle at maximum height	40
(mm)	Maximum Dumping Distance from Frame	441
(°)	Rollback of Bucket on Ground	30
(°)	Rollback of Bucket at Full Height	103
(mm)	Front Turning Radius without Bucket	960
(mm)	Front Turning Radius	1660
(mm)	Rear Turning Radius	1253

Machinery Size
Overall Operating Height
(mm)		3400
Height to top of cab
(mm)		1813
Length Without Bucket
(mm)		2200
Overall Length with Bucket
(mm)		2950
Width
(mm)		920
Bucket Width
(mm)		1070
Height to bottom of flat bucket
(mm)		2446
Height to Bucket Hinge Pin
(mm)		2500
Wheelbase
(mm)		801
Ground Clearance
(mm)		145
Angle of Departure
(°)		20
Distance Between the Rear Axle and the Bumper
(mm)		910
Tread Width
(mm)		785
Tech. Specifications
Bucket capacity
(m³)		0.2
Max Speed
(km/h）		9
Rated flux
(L/min)		50
High Flow Flux
(L/min)		/
Operative weight
(Kg)		1375
Engine Model
		Kubota D1105
Power/revolution speed
(Kw(HP)/rpm)		18,2[24.7]/3000
Fuel tank capacity
(L)		28
Operating load
(kg)		380
Working Range
Dumping height
(mm)		2000
Dumping angle at maximum height
(°)		40
Maximum Dumping Distance from Frame
(mm)		441
Rollback of Bucket on Ground
(°)		30
Rollback of Bucket at Full Height
(°)		103
Front Turning Radius without Bucket
(mm)		960
Front Turning Radius
(mm)		1660
Rear Turning Radius
(mm)		1253
